A-550 PCI-E SSD + SATA 6G Adapter

2013/12/09

Mount 1 x SSD and 3 x SATA HDDs/SSDs in PCIe slot
Compatible with SATA 6G, 3G and 1.5G Hard Drives
Support RAID function: RAID 0, RAID 1, RAID 10 and HyperDuo

  • Ordering Code: A-550
  • Part No: IE-M19-B204-00-00012
  • Solution: 88SE9230

Description: A-550 PCIe SSD+SATA 6G (4 Channels, 1 x int. SSD + 3x int. SATA Ports))Adapter



Features:

* Mount one SSD and three SATA HDDs/SSDs in PCIe slot

* Compliant with PCI-Express Specification v2.0 and backward compatible with PCI-Express 1.x

* Compliant with Serial ATA Specification 3.0

* PCI Express x2 interface, and compatible with PCI Express x4, x8 and x16 slots

* Supports communication speeds of 6.0Gbps, 3.0Gbps, and 1.5Gbps

* Hot plug and Hot Swap

* Supports Native Command Queuing (NCQ)

* Supports Port Multiplier FIS based switching or command based switching

* Compatible with SATA 6G, 3G and 1.5G Hard Drives

* Support RAID function: RAID 0, RAID 1, RAID 10 and HyperDuo



System Requirements:

* PCI Express x4, x8 or x16 slot

* Windows XP/Vista/7/8/10 and Server 2008 R2/2016.



Package Contents

1 x PCIe SSD+SATA 6G Adapter

1 x Driver CD

1 x User Manual

4 x SSD Drive Mount Screws

2 x SATA Cables



Packing Information:

* Retail Blister

* 40pcs. Per carton

* Measurment: 52.7x45.5x35.5 cm

* G.Weight: 10.5 Kg ; N.Weight: 9.2 Kg
