CP-110 PCI POS 4S Serial Card

2013/11/28

Support 4 x UART serial ports
Built-in 16C950 compatible UART
Data transfer rate up to 230400bps

  • Ordering Code: CP-110
  • Part No: IP-X09-5740-00-00012
  • Solution: OXuPCI954

Specification:

* Compliant with PCI 3.0 specification

* Support 4 x UART serial ports

* Built-in 16C950 compatible UART

* 128-bype deep transmit/receive FIFOs

* Data transfer rate up to 230400bps

* Optional RS-232 signal or power output to serial device

* Provides 5VDC or 12VDC power output via pin 1/4/8/9

* 15KV ESD protection on all signal pins

* Plug-n-Play, I/O address and IRQ assigned by BIOS



System Requirements:

* Windows XP/Vista/7/8/8.1/10 (32/64 bit), Linux, Windows CE

* One available PCI slot



Accessories:

1 x Driver CD

1 x User Manual

1 x Fan Out Cable



Packing Information:

* Retail Box Packing

* 40pcs. Per carton

* Measurment: 60x48.5x34.5 cm

* G.Weight: 18.5 Kg ; N.Weight: 17.5 Kg
