I-390 PCI 2S Serial Card

2013/11/04

2 x DB9 male serial connectors
Serial data transfer rate up to 115200bps

  • Ordering Code: I-390
  • Part No: IP-N45-5120-00-00012
  • Solution: MCS9865IV

Specification:   Bus *  PCI 32-bit



Connectors: * 2 x DB9 male serial connectors



Features and Benefits:

*  Compliant with PCI Local Bus Specification, Revision 2.3

*  Supports 2 x UART serial ports

*  Easy Plug and Play

*  Automatically selects IRQ & I/O address

*  Built-in 16C450/550 compatible UART

*  On chip 256 byte FIFOs in transmit and receive path of each serial port

*  Serial data transfer rate up to 115200bps



System Requirements:

* Windows 2000, XP/2003/7/8.x/10/11 (32/64 bit)

* Available PCI slot



Accessories:   1 x Manual, 1 x Driver CD



Packing Information:

* Retail Box Packing

* 50pcs. Per carton

* Measurment: 74 x 38 x 23.5 cm

* G.Weight: 8.3 Kg ; N.Weight: 7.3 Kg
