N-222 PCI Gigabit LAN Card

2014/01/14

1 x RJ45 10/100/1000Mbps Ethernet port
Support Wake on Lan function

  • Ordering Code: N-222
  • Part No: NP-R05-1120-00-00012
  • Solution: RTL8169SC

Description: N-222, REALTEK PCI GIGABIT LAN CARD



Chipset: Realtek Gigabit Ethernet Controller



Bus Interface: PCI V2.2, 32/64-bit, 33/66MHz



Features:

* Compliant to IEEE802.3, IEEE802.3u & IEEE802.3ab

* Supports for IEEE802.3x Full Duplex flow control

* Supports IEEE 802.1Q Virtual LAN (VLAN) Tag

* Compliant to PC97, PC98, PC99 and PC2001 standards

* Auto-Negotiation supports for Auto-Detect 10/100/1000Mbps data rate and Full/Half-Duplex operation mode

* Support ACPI and PCI power management

* Support Boot ROM function (optional)

* Support Wake on Lan function



OS Supports: Supports ODI, NDIS, Windows 98/98SE/ME/2000/XP/NT 4.0, UNIX and Linux, Windows 7/8/10 32/64 bit



Connectors: 1 x RJ-45



Accessories:

1 x Manual, 1 x Driver CD



Packing Information:

* Retail Box Packing

* 80pcs. Per carton

* Measurment: 59.5 x 32 x 37.5 cm

* G.Weight: 8.8 Kg ; N.Weight: 7.8 Kg
