N-270 Switching HUB Gigabit 5 Ports

2014/01/15

5-Port 10/100/1000Mbps Gigabit Switch
144 KBytes on-chip frame buffer

  • Ordering Code: N-270
  • Part No: NN-V11-3511-11-00011
  • Solution: VSC7395

Description: N-270 5-PORT GIGABIT NWAY SWITCH BLUE METAL CASE W/EUR ADAPTOR LAB GIFT BOX



Performance:

* Model:5-Port 10/100/1000Mbps Gigabit Switch

* Buffer Memory:144 KBytes on-chip frame buffer

* Transmission Method:Store-and-forward:

* Status LEDs:

Per Unit: Power

Per Port: 1000 Link /Act and 100 Link/Act

* Forwarding Rate:

10Mbps 14,880/pps

100Mbps 148,800/pps

1000Mbps 1,488,000/pps



Interface Options:

* RJ-45:10BASE-T,100BASE-TX,1000BASE-T Universal UTP Cable Recognition for Straight-Through or Crossover Cables(MDI/MDI-X)



Network Protocol and Standards:

* IEEE:

802.3 Ethernet, 802.3u Fast Ethernet,

802.3u Fast Ethernet, 802.3x Flow

Control & 802.3ab Gigabit Ethernet



Electrical & Electrical Emissions Summary:

* Emissions: CE Mark, FCC Class A

* Power Supply: DC Input: 5V, 2A



Environmental:

* Operating Temperature: 50~131??F(10~55??)

* Operating Humidity: 10~95%(Non-condensing)



Physical Specifications:

* Dimensions(W  / H / D):  16.1 x 8.3 x 2.6 cm



Accessories:

1 x Manual



Packing Information:

* Retail Box Packing

* 10 pcs. Per carton

* Measurment: 36.5 x 28.5 x 22.5 cm

* G.Weight: 11.5 Kg ; N.Weight: 11 Kg
