N-750 Intel PCIe 4-Port 25G SFP28 Network Adapter

2023/07/20

PCIe Gen4 x16 form factor
4 x SFP28 ports
Supports 25Gbps SFP28 and 10Gbps SFP + optics, AOC and DAC modules

  • Ordering Code: N-750
  • Part No: NE-D31-1410-00-00012
  • Solution: Intel E810-CAM1

This high performance PCIe 4-Port 25G SFP28 Network Adapter provides four SFP28 ports for network connection of data rate up to 25Gbps.

By using Intel's top of the class E810 Ethernet controller, the adapter is designed to optimize high-performance system workloads for Cloud and Communications.


Features

PCIe Gen4 x16 form factor

Supports standard and low-profile systems

Provides 4 x SFP28 ports for multiple high-speed connections

Supports 25Gbps SFP28 and 10Gbps SFP + optics, AOC and DAC modules

Various performance optimization technologies: ADQ, DDP, DPDK

Supports IEEE1588 PTP v2 Precision Time Protocol


Requirements

Hardware The following system specs are recommended minimum

PCIe slot: Available 16-Lane PCI-Express slot Gen 4.0 orlater

Processor: Quad Core 3.0GHz or higher

RAM: 4GB memory or higher

Software Operating

systems supported

Windows 11

Windows Server 2016/2019/2022

Linux 3.16 or later


Package Contents

1 x PCIe 4-Port 25G SFP Network Adapter

1 x User Manual
