U-1041 USB 10Gbps to SATA 6G Adapter

2015/06/10

Support USB 10Gbps
Bus bandwidth of Serial ATA up to 6Gbps
Supports both SATA 2.5'' and SATA 3.5'' hard drives

  • Ordering Code: U-1041
  • Part No: U3-A63-DF11-11-00012
  • Solution: ASM235CM

Features

Compliant with USB 3.1 Specification Revision 1.0

Compliant with USB Specifications Revision 2.0

Support USB 10Gbps, USB 5Gbps, High-Speed and Full-Speed Operation

Support USB Mass Storage Class, Bulk-Only Transport Specification Revision 1.3

Support USB Attached SCSI Protocol Specification Revision 1.0

Compliant with Serial ATA Specification Revision 3.2

Bus bandwidth of Serial ATA up to 6Gbps

Support ATA/ATAPI Packet Command Set

Support ATA/ATAPI LBA48 addressing mode

Support both SATA 2.5'' and SATA 3.5'' hard drives

Support SATAATAPI Optical Drives

LED to indicate drive power and activity


System Requirements

Windows 7/8/8.1/10/11 (64 bit)

Available USB Type-A port


Package Contents

1 x USB 10Gbps to SATA 6G Adapter

1 x User Manual

1 x Power Adapter (Optional)

Note: Contents may vary depending on country/market.
