U-1600 PCIe Dual Core USB3.1 4-Port Card

2016/12/26

4 x USB 5Gbps Type-A port
Total transfer bandwidth up to 20Gb/s
Supports 4 downstream ports for all speeds

  • Ordering Code: U-1600
  • Part No: IE-A43-1740-00-00012
  • Solution: ASM1142

Features

PCI-Express 2.0x4

Provides four SuperSpeed+ (10Gb/s) USB 3.1 Type-A ports to support total transfer bandwidth up to 20Gb/s

Complaint with Intel’s eXtensible Host Controller Interface (xHCI) Specification Revision 1.0

Supports simultaneous operation of multiple USB 3.1, USB 2.0 and USB 1.1 devices

Supports the following speed data rates as follows:

Low-speed (1.5Mbps) / Full-speed (12Mbps) / High-speed (480Mbps) / Super-speed (5Gbps)

Supports 4 downstream ports for all speeds

Built-in 4-pin power connector for receiving extra power supply from system

Hot-swapping feature allows you to connect/disconnect devices without powering down the system



System Requirements

Windows 7/8.x/10 (32/64 bit);

Mac OS X 10.10.5 or higher; Linux Kernel 4.6 or later

PCI Express x4, x8 or x16 slots



Package Contents

1 x Dual Channel 4-Port USB 3.1 PCI Express Card

1 x Driver CD

1 x User Manual

Note: Contents may vary depending on country/market.
