U-1630 PCIe USB3.1 2-Port Card (1A+1C)

2017/02/15

1 x USB 10Gbps Type-A port
1 x USB 10Gbps Type-C port

  • Ordering Code: U-1630
  • Part No: IE-A44-1120-00-00012
  • Solution: ASM2142

Features

Support 2 ports of USB3.1

Support PCI Express Gen-Ⅲ x2

Compliant with PCI Express Base 3.0 Specification

Compliant with USB Specification Revision 2.0

Compliant with USB 3.1 Specification Revision 1.0

Up to USB3.1 Gen-Ⅱ 10Gbps Bandwidth Performance with Low Latency

Backward Compatible with USB 3.0/2.0/1.1 Interface

Support Over Current Detection

15-pin SATA Power Connector or 2x4 Auxiliary Power Connector



System Requirements

Windows 7/8/8.1/10 (32/64 bit)

Windows Server 2012

MacOS 10.10 or later

Linux 3.5 or later

One available PCI Express slot (x4, x8, or x16)



Package Contents

1 x PCIe USB 3.1 Card

1 x User Manual

1 x Driver CD

1 x Low Profile Bracket
