U-2020 USB 3.2 Gen 1 Type-C Hub (2A+1C) w/PD

2020/02/20

2x USB 5Gbps Type-A ports
1x USB 5Gbps Type-C port
1 x USB Type-C PD port
Max. current of USB-A port: 1.5A per port
Max. current of USB-C port: 3A per port

  • Ordering Code: U-2020
  • Part No: U3-C49-UH10-11-00012
  • Solution: VL103Q4+VL817

This USB-C Hub adds one 5Gbps USB-C port and two 5Gbps USB-A ports to your laptop or PC.

It supports Power Delivery charging to your laptop side by side with data transfer. Its size is so small that you can put it in your pocket.


Features

Works with USB Type-C enabled smartphone, tablet or computer

Compliant to USB 3.2 Gen1 Specification Revision 1.0 and USB Specification Revision 2.0

2x USB 3.2 Gen 1 5Gbps Type-A ports

1x USB 3.2 Gen 1 5Gbps Type-C port

Supports upstream charging of laptop

Supports Hot Plug Detection

Data transfer rate up to 5Gbps per port

Support USB BC 1.2 for USB-A ports

Max. current of USB-A port: 1.5A per port

Max. current of USB-C port: 3A per port



System Requirements

Windows® 7/8/8.1/10 (32/64 bit)

Mac OS X v10.8 or later

Linux 2.6.24 and 4.11.x or later



Package Contents

1 x USB 5Gbps Type-C Hub

1 x User Manual
