U-980 USB 3.0 Gigabit Ethernet Cable

2015/03/24

Supports Wake-on-LAN
Supports jumbo frame up to 9K bytes
Upstream port: USB 3.0 type A
Downstream port: RJ45 10/100/1000Mbps Ethernet port

  • Ordering Code: U-980
  • Part No: U3-R18-LN10-11-00012
  • Solution: RTL8153

This USB 3.0 to Gigabit Ethernet Cable add a single RJ-45 Ethernet networking port to a USB enabled (USB 3.0) computer system with link speeds up to 1000 Mbps.

Backwards compatible with USB 2.0 computer system and 10/100 Mbps Ethernet networks, this compact and portable cable is ideal as a desktop replacement network adapter or laptop accessory.



Features

Compliant with Universal Serial Bus 3.0 Specification, Revision 1.0

Compatible with USB Specification, Revision 2.0

Supports CDC-ECM

Supports full duplex operation with IEEE 802.3x flow control and half duplex operation with back-pressure flow control

Compatible with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

Supports IEEE 802.3az (Energy Efficient Ethernet)

Supports crossover detection and auto-correction

Supports advanced link down power saving when Ethernet cable is unplugged

Supports Wake-on-LAN

Supports jumbo frame up to 9K bytes

Upstream port: USB 3.0 type A

Downstream port: RJ45

LEDs indicate the status of Power status and Ethernet connection



System Requirements

Windows® XP/Vista/7/8/8.1/10 (32/64 bit); Mac OS X 10.6/10.7/10.8/10.9/10.10; Linux 2.6.27 and up (tested up to 3.13)

Available USB 2.0 port (Recommend USB 3.0 port)



Package Contents

1 x USB 3.0 to Gigabit Ethernet Cable

1 x Driver CD

1 x User Manual



Packing Information:

* Retail Box Packing

* 40pcs. Per carton

* Measurment: 45x42x29 cm

* G.Weight: 5.5 kg

* N.Weigt: 4.4 kg
