N-620 PCIe 2-Port 10G 5-Speed Network Adapter

2019/03/18

2 x RJ45 port
Support 5-Speed 10Gb/5Gb/2.5Gb/1Gb/100Mb auto negotiation
Runs up to 10G at 100m Cat 6A cable and 5G at 100m Cat 5e/Cat 6 cable
9K Jumbo Frames

  • Ordering Code: N-620
  • Part No: NE-T18-1210-00-00012
  • Solution: TN4010

This card is a Multi-Gigabit network adapter that's runs on a high speed PCIe x4 host bus interface.

This card hosts the Tehuti's new 3rd generation TN4010 controller, and optimized 10 Gigabit Ethernet MAC designed for low-power, low-cost, single-port connectivity required by Application Servers and Workstations.

The TN4010 MAC is paired with Marvell Alaska 88X3310P transceiver, a low-power, high-performance 10 Gigabit Ethernet PHY, to enable five-speed connectivity (10GBase-T, 5GBase-T 2.5GBase-T 1000Base-T, and 100Base-TX) over low-cost standard CAT-6a Ethernet cabling, up to 100m (Cat-5e and CAT-6 are supported compliant to Link Segment specifications).

This combination creates a new gateway to cost-conscious consumer applications, as well as to intensive data environments.


Features

Support 5-Speed 10Gb/5Gb/2.5Gb/1Gb/100Mb auto negotiation

Runs up to 10G at 100m Cat 6A cable and 5G at 100m Cat 5e/Cat 6 cable

Backward compatibility with 1000Base-T, 100Base-T Networks

PCI Express Gen-2 x8 host bus interface

EEE (Energy Efficient Ethernet)

9K Jumbo Frames

IP, TCP, UDP checksum offloading

IEEE 802.1Q VLAN

Virtual NIC support

Reduced CPU utilization and improved throughput



Requirements

Hardware

The following system specs are recommended minimum

PCIe slot: Available 4-Lanes PCI-Express slot gen 2.0 or later

Processor: Quad Core 3.0GHz or higher

RAM: 4GB memory or higher

Software

Operating systems supported are (both 32 and 64 bits)

Windows 7/8.1/10

Windows Server 2008 R2/2012/2012R2

Linux 2.6.32 - 4.x Versions only

VMware ESXi 5.x/6.0

Mac OS X 10.12.6 or later



Package Contents

1 x PCIe 10G 5-Speed Multi-Gigabit Network Card

1 x Low profile bracket

1 x Driver CD

1 x User Manual
